Page 6 HydroRanger 200 – INSTRUCTION MANUAL 7ML19985FC03
mmmmm
Specifications
Inputs
mA (analog) (1) [6 relay model]
• 0-20 or 4-20 mA, from alternate device, scalable
Discrete (2)
• 10-50 V DC switching level
• logical 0 = < 0.5 V DC
• logical 1 = 10 to 50 V DC
• 3 mA maximum draw
Enclosure
Wall Mount
• 240 mm (9.5") x 175 mm (6.9"). Width dimension includes hinges.
• Type 4X / NEMA 4X / IP 65
1
• Polycarbonate
Panel Mount
• 278 mm (10.93") x 198 mm (7.8") Width dimension includes flange.
• Type 3 / Nema 3 / IP54
• Polycarbonate
Weight
• Wall mount: 1.37 kg (3.02 lb)
• Panel mount: 1.5 kg (3.3 lb)
Approvals
• See product nameplate
Compatible Transducers
• Echomax series and STH series
Transducer Frequency
•44 kHz
1.
For watertight applications, use only approved, suitable size hubs in the
enclosure’s conduit holes.
