Page 74 HydroRanger 200 – INSTRUCTION MANUAL 7ML19985FC03

mmmm

Open Channel Monitoring

6 Relay Model

BS-3680 / ISO 4359 Rectangular Flume

P603 G Maximum Head (preset to P007)

P801 G Range Extension

P608 G Flowrate Units

Parameter Index Value

P600 G 6–ISO 4359 Rectangular Flume

P602 1 Approach width (B)

2 Throat width (b)

3 Hump Height (p)

4 Throat length (L)

(view only) 5 Velocity coefficient (Cv)

Parameter Index Value

Diagonal View

Plan View

4 to 5 x h

max

= P007)

Flow

Transducer

P006

P605 (p)

Flow

Front View Side View
