Page 14 HydroRanger 200 – INSTRUCTION MANUAL 7ML19985FC03

mmmmm

Installation

Installing SmartLinx Card

SmartLinx cards are generally pre-installed. If unit does not have a SmartLinx card, follow

these steps to install one.

1. Align card with the two mounting posts and then press-fit with the female

connector.

2. Use the screws supplied with the card to attach it to the mounting posts.

3. Wire in the SmartLinx card according to SmartLinx Manual.
