Page 82 HydroRanger 200 – INSTRUCTION MANUAL 7ML19985FC03

mmmm

Open Channel Monitoring

6 Relay Model

Example Flumes

These example flumes would both require a universal calculation.

Trapezoidal

Dual Range (nested) Parshall

Example Weirs

These weirs could require universal calculation.

contracted

rectangular

compound Poebing approximate

exponential
