29 Parameter list LMV36...
Par. Parameter Number of Type Edit Value range Resolution Default Password level
no. LMV36... elements Min Max setting
000 Internal parameters
041 Password heating engineer (4 characters) 1 Std_u16 Edit 0 65535 1 OEM
042 OEM password (5 characters) 1 Std_u16 Edit 0 65535 1 OEM
050 Backup / Restore via AZL2... / PC software starting (parameterizing
on 1)
Index 0 = store backup
Index 1 = start restore
Error diagnostic via negative value (refer to error code 137)
2 Std_s8 Edit -99 50 1 0; 0 SO
055 Burner ID of AZL2... backup data record 1 Std_s32 Read only 0 99999999 1 0 SO
056 ASN summary of AZL2... backup data record 8 Std_u8 Read only 0 127 1 0 SO
057 Software version when setting the AZL2... backup data record 1 Hex_16 Read only 0x100 0xFFF9 1 0 SO
100 General
102 Identification date 1 Date Read only 0 255 1 Info / Service
103 Identification number 1 Std_u16 Read only 0 65535 1 Info / Service
104 Preselected parameter set: Customer code 1 Std_u8 Read only 0 255 1 9 Info / Service
105 Preselected parameter set: Version 1 Hex_16 Read only 0 0xFFFF 1 V 01.06 Info / Service
107 Software version 1 Hex_16 Read only 0x100 0xFFF9 1 V 03.40 Info / Service
108 Software variant 1 Std_u8 Read only 0 255 1 2 Info / Service
111 ASN summary for verification with AZL2... backup data restore 8 Std_u8 Read only 0 127 1 0 SO
113 Burner identification 1 Std_s32 Edit 0 99999999 1 undefined Info / Service
Password level
write: SO
121 Manual output
Undefined = automatic mode
1 Output Edit / clear 0% 100% 0.1% undefined Info / Service
123 Minimum output positioning step
Index 0 = output building automation
Index 1 = output external load controller analog
Index 2 = reserved
3 Output Edit 0 % 100 % 0.1 % Index
0
1
2
Value
0%
1%
0%
SO
124 Loss of flame test (TÜV test) starting (parameterized on 1)
(switch off the fuel valves
 loss of flame)
1 Std_s8 Edit -6 1 1 0 SO
