Siemens LMV5 Series Basic Documentation

Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
123/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
MinT_PrepurgeO
il
Minimum prepurge time oil 0.2..63 min OEM 15s x x
PrepurgeSafeGa
s
Prepurge time after safety shutdown gas MinT_PrepurgeGas..63
min
OEM 20s x x
PrepurgeSafeOil Prepurge time after safety shutdown oil MinT_PrepurgeOil..63 min OEM 15s x x
PreIgnitionTGas Preignition time gas 0.2..63 s OEM 2s x x
PreIgnitionTOil Preignition time oil 0.2..44 s OEM 2s x x
MinOnTmeOilPu
mp
Minimum on time of oil pump 0.2..63 s OEM 1s x x
TimesStartup2 Burner control startup times 2 Service x x
SafetyTme1Gas Safety time 1 gas 1 s..MaxSafetyTGas OEM 2s x x
SafetyTme1Oil Safety time 1 oil 1 s..MaxSafetyTOil OEM 2s x x
Interval1Gas Interval 1 (ts1-ts2) gas 0.2..63 s Service 2s x x
Interval1Oil Interval 1 (ts1-ts2) oil 0.2..63 s Service 2s x x
SafetyTme2Gas Safety time 2 gas 1 s..MaxSafetyTGas OEM 2s x x
SafetyTme2Oil Safety time 2 oil 1 s..MaxSafetyTOil OEM 2s x x
Interval2Gas Interval 2 (ts2 operation) gas 0.2..63 s Service 2s x x
Interval2Oil Interval 2 (ts2 operation) oil 0.2..63 s Service 2s x x
PressReacTme Reaction time to lack of pressure in ts1 and ts2 0.2s..MaxSafetyTGas OEM 1s x x
TimesShutdow
n
Burner control shutdown times Service x x
MaxTmeLowFire Maximum time to low-fire in operation 2 0.2..630 s Service 45s x x
AfterburnTme Afterburn time 0.2..63 s OEM 8s x x
PostpurgeT1Gas Postpurge time 1 gas 0.2..63 min OEM 0.2s x x
PostpurgeT1Oil Postpurge time 1 oil 0.2..63 min OEM 0.2s x x
PostpurgeT3Gas Postpurge time 3 gas 0.2..63 min Service 5s x x
PostpurgeT3Oil Postpurge time 3 oil 0.2..63 min Service 5s x x
MinTmeHomeRu
n
Minimum time in home run phase 0.2..63 s OEM 1s x x
DelayLackGas Basic waiting time in the event of lack of gas MinTmeHomeRun ..63s OEM 10s x x
TimesGeneral General times of burner control Service x x
AlarmDelay Time to alarm in the event of start prevention and heat demand 0.4..630 s Service 35s x x
