Siemens LMV5 Series Basic Documentation

Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
124/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
DelayStartPrev Time until message on start prevention and heat demand is
delivered
0.4..630 s Service 35s x x
PostpurgeLocko
ut
Postpurge in lockout position 0.2..63 min OEM 0.2s x x
MaxTmeStartRel Maximum phase time start release (timeout) 0.2..630 s OEM 120s x x
Configuration Service x x
ConfigGeneral General parameters of burner control Service x x
AlarmStartPrev With/without alarm in the event of start prevention and heat
demand
deactivated
activated
Service deactivated x x
NormDirectStart Normal/direct start in the event of heat demand in phase 78 NormalStart
DirectStart
OEM NormalStart x x
OilPumpCouplin
g
Configuration for coupling the oil pump Magnetcoupl
Directcoupl
OEM Magnetcoup
l
x x
IgnOilPumpStart Switch-on time of ignition and oil pump on in Ph38
on in Ph22
OEM on in Ph38 x x
ForcedIntermit With / without forced intermittent operation deactivated
activated
Service activated x x
ContinuousPurg
e
Configuration for normal or continuous fan operation deactivated
activated
OEM deactivated x x
FuelTrainGas Fuel train when firing on gas DirectIgniG
Pilot Gp1
Pilot Gp2
OEM invalid x x
FuelTrainOil Fuel train when firing on oil LightOilLO
HeavyOilHO
LO w Gasp
HO w Gasp
OEM invalid x x
FuelTrainReset Resetting the fuel train to invalid value OEM x x
FuelTrainGas OEM x x
FuelTrainOil OEM x x
MainsFrequency Selection of mains frequency 50 Hz/60 Hz 50 Hz
60 Hz
OEM 50 Hz x x
ConfigIn/Output Configuring the inputs and outputs OEM x x
