SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 3-119
In addition, you can delete the previously drawn machining lines in the
graphics in order to get a clear display.
Details
>
 Press the "Details" softkey.
Original cut-away
Back to
original
 Press the "Back to original" softkey to restore the original size of
the viewport.
The workpiece on the main spindle or counter-spindle appears.
Zoom
Zoom
+
or
+
 Press the "Zoom +" or "+", softkey if you would like to enlarge the
cut-away.
-or-
Zoom
-
or
 Press the "Zoom -" or "-", softkey if you would like to decrease the
size of the cut-away.
-or-
 Press a cursor key if you want to pan the cut-away up, down, left,
or right.
The new cut-away appears.
Magnifying glass
Zoom
 Press the "Zoom" softkey.
A magnifying glass in the shape of a rectangular frame appears.
 Press a cursor key if you want to move the magnifying glass up,
down, left, or right.
Magnifying
glass +
 Press the "Magnifying glass +" softkey if you want to enlarge the
cut-away that you selected with the magnifying glass.
-or-
Magnifying
glass -
 Press the "Magnifying glass -" softkey if you want to decrease the
size of the cut-away that you selected with the magnifying glass.
Magnifying
glass zoom
 Press the "Magnifying glass zoom" softkey.
The new cut-away appears.
Deleting machining lines
 Press the "Del" key.
The previous machining lines are deleted.
