Siemens MCP 398C Operation/Programming

5
ShopTurn Functions 08/2005
5.5 Millin
g
5
♥ Siemens AG, 2005. All rights reserved
5-238 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
X0
Y0
L0
C0
Z0
Z1
DXY
DZ
UXY
UZ
FS
ZFS
Single position End face/End face C:
The reference point is always the center point of the rectangular pocket.
Reference point in X direction (abs.)
Reference point in Y direction (abs.)
Reference point on longitudinal polar axis (alternative to X0)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Pocket depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum infeed in the XY plane – (for roughing and finishing only)
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in the plane (pocket edge) – (for roughing and finishing only)
Finishing allowance in depth (pocket base) – (for roughing and finishing only)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
mm
mm
mm
Degrees
mm
mm
mm
%
mm
mm
mm
mm
mm
Y0
C0
Z0
X0
X1
DYZ
DX
UYZ
UX
FS
ZFS
Single position Peripheral surface/Peripheral surface C:
The reference point is always the center point of the rectangular pocket.
Reference point in Y direction (abs.)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Cylinder diameter ¬ (abs.)
Pocket depth based on X0 (abs or inc) – (only for roughing and finishing)
Maximum infeed in the YZ plane – (for roughing and finishing only)
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (X direction) – (for roughing and finishing only)
Finishing allowance in the plane (pocket edge) – (for roughing and finishing only)
Finishing allowance in depth (pocket base) – (for roughing and finishing only)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
mm
Degrees
mm
mm
mm
mm
%
mm
mm
mm
mm
mm
CP
X0
Y0
L0
C0
Z0
Z1
DXY
DZ
UXY
UZ
FS
ZFS
Single position End face Y:
The reference point is always the center point of the rectangular pocket.
Positioning angle for machining area
Reference point in X direction (abs.)
Reference point in Y direction (abs.)
Reference point on longitudinal polar axis (alternative to X0)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Pocket depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum infeed in the XY plane – (for roughing and finishing only)
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in the plane (pocket edge) – (for roughing and finishing only)
Finishing allowance in depth (pocket base) – (for roughing and finishing only)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
Degrees
mm
mm
mm
Degrees
mm
mm
mm
%
mm
mm
mm
mm
mm
