SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-245
Spigot >
Rectangu-
lar spigot
¾ Press the "Milling", "Spigot" and "Rectangular spigot" soft keys.
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
Position Select from 6 different positions:
End face/End face C – Front
End face/End face C – Rear
End face Y – Front (only when Y axis exists)
End face Y – Rear (only when Y axis exists)
Peripheral surface Y – inner (only when Y axis exists)
Peripheral surface Y – Rear (only when Y axis exists)
Clamp/release spindle (for End face Y/Peripheral surface Y only)
The function must be set up by the machine manufacturer.
Machining
type
Roughing
Finishing
Chamfer
Einzelpos.
Pos. Muster
Mill rectangular spigot at the programmed position (X0, Y0, Z0, L0, C0, CP).
Mill several rectangular spigots in a positioning pattern (full circle or matrix).
X0
Y0
L0
C0
Z0
Z1
DZ
UXY
UZ
FS
ZFS
Single position End face/End face C:
The reference point is always the center point of the rectangular spigot.
Reference point in X direction (abs.)
Reference point in Y direction (abs.)
Reference point on longitudinal polar axis (alternative to X0)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Spigot depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in depth (spigot edge) – (for roughing and finishing only)
Finishing allowance in depth (spigot depth) – (for chamfer only)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
mm
mm
mm
Degrees
mm
mm
mm
mm
mm
mm
mm
