Siemens MCP 398C Operation/Programming

5
08/2005 ShopTurn Functions
5.5 Millin
g
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-265
Z1
FZ
W
DX1
DX2
α1
α2
Machining depth (inc.)
Depth infeed rate
Character height
Character spacing
Total width (alternative to DX1) – (for linear alignment only)
Text direction (for linear alignment only)
Arc angle (alternative to DX1) – (for curved alignment only)
The center point of the arc is the workpiece zero.
mm
mm/min
mm/tooth
mm
mm
mm
Degrees
Degrees
Y0
C0
R
Z0
α0
X0
X1
FX
W
DY1
DY2
α1
α2
YM
CM
ZM
Peripheral surface/Peripheral surface C:
Reference point in Y direction (abs.)
Reference point (alternative to Y0) – (for linear alignment only)
Reference point on longitudinal polar axis (alternative to Y0) – (for curved alignment
only)
Reference point in Z direction (abs.)
Reference point on angular polar axis (alternative to Z0) – (for curved alignment
only)
Reference point in X direction (abs.)
Machining depth (inc.)
Depth infeed rate
Character height
Character spacing
Total width (alternative to DY1) – (for linear alignment only)
Text direction (for linear alignment only)
Arc angle (alternative to DY1) – (for curved alignment only)
Center point of arc (abs.) – (for curved alignment only)
Center point of arc (abs.) – (alternative to YM)
Center point of arc (abs.) – (for curved alignment only)
mm
mm
mm
mm
Degrees
mm
mm
mm/min
mm/tooth
mm
mm
mm
Degrees
Degrees
mm
Degrees
mm
CP
X0
L0
Y0
C0
Z0
Z1
FZ
W
DX1
DX2
α1
α2
End face Y:
Positioning angle for machining area
Reference point in X direction (abs.)
Reference point on longitudinal polar axis (alternative to X0)
Reference point in Y direction (abs.)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Machining depth (inc.)
Depth infeed rate
Character height
Character spacing
Total width (alternative to DX1) – (for linear alignment only)
Text direction (for linear alignment only)
Arc angle (alternative to DX1) – (for curved alignment only)
The center point of the arc is the workpiece zero.
mm
mm
mm
Degrees
mm
mm
mm/min
mm/tooth
mm
mm
mm
Degrees
Degrees
