5
08/2005 ShopTurn Functions
5.6 Contour millin
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-287
Approach
mode
Approach mode:
In a quadrant: Part of a spiral (only with path milling left and right of the contour)
In a semicircle: Part of a spiral (only with path milling left and right of the contour)
In a straight line: Slope in space
Perpendicular: Perpendicular to the path (only with path milling on the center path)
Approach
strategy
Axis by axis
spatial (not with perpendicular approach mode)
R1 Approach radius (only for quadrant or semicircle approach mode) mm
L1 Approach distance (only for straight-line approach mode) mm
FZ Depth infeed feedrate
(for end face/end face C and end face Y with axis-by-axis approach strategy)
mm/tooth
mm/min
FX Depth infeed feedrate
(for peripheral surface/peripheral surface C and peripheral surface Y with axis-by-
axis approach strategy)
mm/tooth
mm/min
Retract mode Retract mode
In a quadrant: Part of a spiral (only with path milling left and right of the contour)
In a semicircle: Part of a spiral (only with path milling left and right of the contour)
In a straight line: Slope in space
Perpendicular: Perpendicular to the path (only with path milling on the center path)
Retract
strategy
Axis by axis
Three-dimensionally (not with perpendicular retraction mode)
R2 Retraction radius (only for quadrant or semicircle retraction mode) mm
L2 Retraction distance (only for straight-line retraction mode) mm
Retraction
mode
If more than one depth infeed is necessary, specify the retraction height to which the
tool retracts between the separate infeeds (in the transition from the end of the
contour to the beginning).
To retraction plane
Z0+safety clearance (for end face/end face C and end face Y only) or X0+safety
clearance (for peripheral surface/peripheral surface C and peripheral surface Y
only)
Safety clearance
No retraction
