5
ShopTurn Functions 08/2005
5.6 Contour millin
5
♥ Siemens AG, 2005. All rights reserved
5-286 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Radius
compensation
Input defining which side of the contour the milling cutter machines in the
programmed direction:
Machining to the right of the contour
Machining to the left of the contour
Machining along the center path
Z0
Z1
DZ
UZ
UXY
FS
ZFS
End face/End face C:
Reference point in Z direction (abs.)
Depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in depth (for roughing only)
Finishing allowance in the plane (only for roughing and to the left of the contour)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
mm
mm
mm
mm
mm
mm
mm
Slot wall offset
D
X0
X1
DX
UX
UYZ
FS
ZFS
Peripheral surface/Peripheral surface C:
Activate slot wall offset
Offset to programmed path (only with activated slot wall offset)
Cylinder diameter ¬ (abs.)
Depth based on Z0 ¬ (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (X direction) – (for roughing and finishing only)
Finishing allowance in depth (for roughing only)
Finishing allowance in the plane (only for roughing and to the left of the contour)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
mm
mm
mm
mm
mm
mm
mm
mm
CP
Z0
Z1
DZ
UZ
UXY
FS
ZFS
End face Y:
Reference point
Reference point in Z direction (abs.)
Depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in depth (for roughing only)
Finishing allowance in the plane (only for roughing and to the left of the contour)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
Degrees
mm
mm
mm
mm
mm
mm
mm
C0
X0
X1
DX
UX
UYZ
FS
ZFS
Peripheral surface Y:
Reference point
Reference point in X direction (abs.)
Depth based on X0 (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (X direction) – (for roughing and finishing only)
Finishing allowance in depth (for roughing only)
Finishing allowance in the plane (only for roughing and to the left of the contour)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
Degrees
mm
mm
mm
mm
mm
mm
mm
