8
08/2005 Tool Management
8.1 Tool lists
tool wear lists and the tool ma
azine
8
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 8-355
For chain and disk magazines, the locations for a spindle and a dual-
gripper can also be displayed.
Please also refer to the machine manufacturer's instructions.
Spindle location
Locations for grippers 1 and 2
Type Tool type and cutting edge position
Using the "Alternative" key, you can change the tool’s cutting edge
position.
Tool name The tool is identified by its name. The tool name can be specified as
text or numbers.
DP Duplo-number of the sister tool (replacement tool)
(DP 1 = original tool, DP 2 = first replacement tool,
DP 3 = second replacement tool, etc.)
Tool offset data
You can find a detailed description of the tool offset data in Sec.
"Setting-up the Machine" (Section "Tools").
(D No.) edge The tool offset data shown here is valid for the currently selected
cutting edge of a tool.
Length X Tool length compensation in the X direction
Length Z Tool length compensation in the Z direction
Radius or ¬
Radius or diameter of the tool
For milling and drilling tools, you can also specify the radius or the
diameter. For turning tools, you always specify the cutting edge
radius. A machine data code is used to switch from radius to diameter
specification.
Please also refer to the machine manufacturer's instructions.
Reference direction for the holder angle
The holder angle of a cutting tool
The holder angle of a cutting tool is taken into consideration when
machining rear cuts.
The plate angle of a cutting tool
The plate angle of a cutting tool is taken into consideration when
machining rear cuts.
Lead Thread pitch of a tap drill in mm/rev or thread intervals/''
Drill-¬
Diameter of the drill hole for a rotary drill
Plat.width Plate width of a pin
The plate width needs ShopTurn for calculating the groove cycles.
