8
Tool Management 08/2005
8.1 Tool lists
tool wear lists and the tool ma
azine
8
♥ Siemens AG, 2005. All rights reserved
8-356 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Plat.length The plate length of a cutting tool or pin
The plate length needs ShopTurn for displaying the tools during the
program execution simulation.
N Number of teeth for a milling cutter
The number of teeth for a milling machine
From this, the controller internally calculates the rotational feedrate if
the feedrate is set in mm/tooth in the program.
Angle of the tool tip for a drill
When drilling, if you want to plunge as far as the shaft and not only as
far as the tool tip, the controller takes the angle of the drill tip into
consideration.
Tool-specific
specifications
Specification of the spindle’s direction of rotation
The direction of the spindle’s rotation is relative to the tool spindle for
powered tools (drilling and milling machines) and to the main or
counter-spindle for turning tools.
If you are using a drilling or milling machine for "axial drilling" or "axial
threading", the specified direction of rotation is relative to the cutting
direction of the tool. The main spindle then rotates adapting to the
tool.
Direction of spindle rotation to the right
Direction of spindle rotation to the left
Spindle not switched on
Coolant supply 1 and 2 (e.g. internal and external cooling) ON/OFF
during use of this tool
Coolant ON
Coolant OFF
Observe that some machines do not have a coolant supply.
Please also refer to the machine manufacturer's instructions.
