11
Examples
08/2005
11.1 Standard
machinin
g
p
rocesses
11
♥
Siemens AG, 2005. All rig
hts reserved
11-412
SINUMERIK 840D sl Operati
on/Programmin
g ShopTurn (BAT) – 0
8/2005 Edition
îš¾
Press
the
softkey
Finished-part contour
6.
Stock removal (roughing)
îš¾
Press
the
Stock
removal
softkeys
îš¾
Enter
parameters:
T
Roughing tool_80
F
0.300 mm/rev
V
200 m/min
Machining
Direction
of
Stock
Removal
Longitudinal (parallel to the Z-axis)
Machining
side
Exterior
Machining
direction
.
(from front to back)
D
1.9 inc.
Cutting
depth
UX
0.2 inc.
UZ
0.1 inc.
BL
Contour
Limit
No
Rear
cut
No
îš¾
Press
the
softkey
411
413
