Siemens MD-BMS - Page 66

Appendices
Appendix A
-
MD
-
BMS and MD
-
BMED Power Meters BACnet Analog Val
ue Objects
66
Building Technologies 125-202
06/06/2017
Object
Identifier
Name Description
(resettab
le) (Signed Net)
1100 kW System Max System Highest Instantaneous Draw Since Reset (kW)
1110 kW System Maximum Positive System Highest Instantaneous Positive Draw Since Reset (kW) (Signed Net)
1120 kW System Maximum Negative System Highest Instantaneous Negative Draw Since Reset (kW)
1130 kW System Min System Lowest Instantaneous Draw Since Reset (kW, resettable)
1140 kW System Minimum Positive System Lowest Instantaneous Positive Draw Since Reset (kW, resettable)
1150 kW System Minimum Negative System Lowest Instantaneous Negative Draw Since Reset (kW, resettable)
1160 kW L1 Individual Phase True Power (kW) (Signed)
1190 kW L2 "
1220 kW L3 "
2000 kWh Sys Total System True Energy (kWh) (Unsigned/Absolute)
2010 kWh System Total Positive System True Energy Positive (kWh) (Signed Net)
2020 kWh System Total Negative System True Energy Negative (kWh) (Signed Net)
2021 kWh System Total Net System True Energy (kWh) Net
2040 kWh L1 Positive Individual Phase True Energy (kWh) (Signed)
2050 kWh L1 Negative "
2051 kWh L1 Net Individual Phase True Energy (kWh) (Net)
2070 kWh L2 Positive Individual Phase True Energy (kWh) (Signed)
2080 kWh L2 Negative Individual Phase True Energy (kWh) (Signed)
2081 kWh L2 Net Individual Phase True Energy (kWh) (Net)
2100 kWh L3 Positive Individual Phase True Energy (kWh) (Signed)
2110 kWh L3 Negative " Individual Phase True Energy (kWh) (Signed)
2111 1kWh L3 Net Individual Phase True Energy (kWh) (Net)
3000 Volts LL Avg Voltage Line to line Average
3010 Volts LN Avg Voltage Line to neutral Average
3020 Volts L1 L2 Individual Phase to Phase Voltages
3030 Volts L2 L3 "
3040 Volts L1 L3 "
3050 Volts L1N Individual Phase to Neutral Voltages (V)
3060 Volts L2N "
