BMED Power Meters BACnet Analog Value Objects
67
Building Technologies 125-202
06/06/2017
Object
Identifier
Name Description
3070 Volts L3N "
4010 Amps Sys Avg Average of all phases.
4020 Amps L1 Individual Phase Currents (A)
4030 Amps L2 "
4040 Amps L3 "
5000 kVAR Sys System Total Reactive Power (kVAR). Unsigned absolute value of (kVAR L1)
+ (kVAR L2) + (kVAR L3)
5001 kVAR Sys Net System Total Reactive Power (kVAR). Signed net value of (kVAR L1) +
(kVAR L2) + (kVAR L3)
5030 kVAR L1 Individual Phase Reactive Energy LSW (kVARh) (Signed)
5060 kVAR L2 "
5090 kVAR L3 "
5120 kVAR Dem System Max System Maximum Instantaneous kVAR Demand (kVA, resettable). It displays
the default value after a CAM until 1 demand window elapses. After a power
cycle or CPU reset, the value is not reset and does not update again until 1
demand window elapses. (Unsigned/Absolute)
5130 kVAR Dem SystemNow Average kVAR demand for most recent window (resettable). Displays the
default value after a CAM or reset, or power cycle. Updates every minute
thereafter. True demand value takes a demand period to get to actual value.
(Unsigned/Absolute)
6010 kVARh Net System System Total Reactive Energy (Unsigned/Absolute)
6020 kVARh System Total Positive System True Energy (kVARh) Positive (Signed Net)
6030 kVARh Sys Negative System Total Reactive Energy (Signed Net)
6050 kVARh L1 Positive Individual Phase Reactive Energy (kVARh) (Signed)
6060 kVARh L1 Negative "
6080 kVARh L2 Positive "
6090 kVARh L2 Negative "
6110 kVARh L3 Positive "
6120 kVARh L3 Negative "
7000 kVAh System Total System Total Apparent Energy (Unsigned/Absolute)
7001 kVAh System Total Positive System Total Positive Apparent Energy (kVAh) (Signed Net).
Accumulates only when kW is positive.
7002 kVAh System Total Negative System Total Negative Apparent Energy (Signed Net)
7020 kVAh L1 Positive Individual Phase Apparent Energy LSW (kVAh) (Signed)
7030 kVAh L1 Negative Individual Phase Apparent Energy (kVAh) Signed
