BMED Power Meters Modbus Absolute/Net Value Measurement Registers and
Protocol Commands
80
Building Technologies 125-202
06/06/2017
Table 20: Pulse Output/Input Registers
Modbus Offset Register Description
44402 4401 Port 1 output control when used
as an on/off-open/closed switch
0 = Output LOW (closed)
1 = Output HIGH (open) [default]
Register 45110 must = 0 to use.
45110 5109 Digital Port 1 Configuration Turns
pulses on/off
0 = No pulses, Port may be used as an on/off-open/closed switch
44001 = System kWh pulses
44008 = System kVARh pulses
44011 = System kVAh pulses
45111 5110 Port 1 pulse output relay type 0 = Normally open (HIGH)
1 = Normally closed (LOW)
Table 21: Positive Power/Energy Measurement Registers.
Modbus Offset Register Description
46001 6000 Positive kWh System LSW System Positive True Energy LSW (kWh,
resettable)
46002 6001 Positive kWh System MSW System Positive True Energy MSW (kWh,
resettable)
46003 6002 Positive kW System System Positive Instantaneous Positive True
Power (kW) (net sum of all individual kWs, if sum
is negative value = 0).
46004 6003 kW Demand System Max System Maximum Demand (peak demand)
46005 6004 kW Demand System Now Average Power (kW) for most recent demand
window
46006 6005 Positive kW System Max System Net Highest Instantaneous Positive Draw
Since Reset (kW, resettable)
46007 6006 Positive kW System Min System Net Lowest Instantaneous Positive Draw
Since Reset (kW, resettable)
46008 6007 Positive kVARh System LSW System Net Positive Reactive Energy LSW
(kVARh, resettable)
46009 6008 Positive kVARh System MSW System Net Positive Reactive Energy MSW
(kVARh, resettable)
46010 6009 Positive kVAR System System Net Instantaneous Positive Reactive
Power (kVAR) (net sum of all individual kVARs, if
sum is negative value = 0)
46011 6010 kVAh System LSW System Apparent Energy, LSW (resettable)
46012 6011 kVAh System MSW System Apparent Energy, MSW (resettable)
46013 6012 kVA System System Instantaneous Apparent Power
46014 6013 Positive Displacement PF System System Positive Displacement Power Factor
(dPF); Register is 100 × actual value (If the
System dPF (44014) is positive, this register will
