Appendices
Appendix B
-
MD
-
BMS and MD
-
B
MED Power Meters Modbus Absolute/Net Value Measurement Registers and
Protocol Commands
81
Building Technologies 125-202
06/06/2017
Modbus Offset Register Description
co
ntain that value; otherwise, it will be zero).
46015 6014 Positive Apparent PF System System Positive Apparent Power Factor (aPF);
Register is 100x actual value (If the System aPF
(44015) is positive, this register will contain that
value; otherwise, it will be zero).
46016 6015 Amps System Avg Average of the current in all phases.
46017 6016 Volts Line to Line Avg Average of the system line to line voltages.
46018 6017 Volts Line to Neutral Avg Average of the system line to neutral voltages.
46019 6018 Volts L1 to L2 Individual phase to phase voltages
46020 6019 Volts L2 to L3 “
46021 6020 Volts L3 to L1 “
46022 6021 Measured Line Frequency Line frequency x 10 (e.g., 602 = 60.2 Hz). On
startup, 20 point averaging array is filled with first
frequency read.
46023 6022 Positive kWh L1 LSW Individual Phase Positive True Energy LSW (kWh,
resettable)
46024 6023 Positive kWh L1 MSW Individual Phase Positive True Energy MSW
(kWh, resettable)
46025 6024 Positive kWh L2 LSW "
46026 6025 Positive kWh L2 MSW "
46027 6026 Positive kWh L3 LSW "
46028 6027 Positive kWh L3 MSW "
46029 6028 Positive kW L1 Individual Phase Instantaneous Positive True
Powers (kW)
46030 6029 Positive kW L2 "
46031 6030 Positive kW L3 "
46032 6031 Positive kVARh L1 LSW Individual Phase Positive Reactive Energy LSW
(kVARh, resettable)
46033 6032 Positive kVARh L1 MSW Individual Phase Positive Reactive Energy MSW
(kVARh, resettable)
46034 6033 Positive kVARh L2 LSW "
46035 6034 Positive kVARh L2 MSW "
46036 6035 Positive kVARh L3 LSW "
46037 6036 Positive kVARh L3 MSW "
46038 6037 Positive kVAR L1 Individual Phase Positive Instantaneous Reactive
Powers (kVAR)
