Appendices
Appendix E
–
Modbus VER
IS H8035/H8036 Emulation
97
Building Technologies 125-202
06/06/2017
Table 32: Veris Multipliers for Integer Registers 40001-40027.
Address Units ≤ 100A 101-400A 401-800A 801-1600A 1601-32,000A
40001 kWH LSB 7.8125exp-3 0.03125 0.0625 0.125 0.25
40002 kWH MSB 512 2048 4096 8192 16384
40003 kW 0.004 0.016 0.032 0.064 0.128
40004 kVAR 0.004 0.016 0.032 0.064 0.128
40005 kVA 0.004 0.016 0.032 0.064 0.128
40006 aPF 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5
40007 VOLTS L-L 0.03125 0.03125 0.03125 0.03125 0.03125
40008 VOLTS L-L 0.015625 0.015625 0.015625 0.015625 0.015625
40009 AMPS 3.9063exp-3 0.015625 0.03125 0.0625 0.125
40010 kW L1 0.001 0.004 0.008 0.016 0.032
40011 kW L2 0.001 0.004 0.008 0.016 0.032
40012 kW L3 0.001 0.004 0.008 0.016 0.032
40013 aPF L1 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5
40014 aPF L2 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5
40015 aPF L3 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5
40016 VOLTS L1-L2 0.03125 0.03125 0.03125 0.03125 0.03125
40017 VOLTS L2-L3 0.03125 0.03125 0.03125 0.03125 0.03125
40018 VOLTS L3-L1 0.03125 0.03125 0.03125 0.03125 0.03125
40019 VOLTS L1-N 0.015625 0.015625 0.015625 0.015625 0.015625
40020 VOLTS L2- N 0.015625 0.015625 0.015625 0.015625 0.015625
40021 VOLTS L3- N 0.015625 0.015625 0.015625 0.015625 0.015625
40022 AMPS L1 3.9063exp-3 0.015625 0.03125 0.0625 0.125
40023 AMPS L2 3.9063exp-3 0.015625 0.03125 0.0625 0.125
40024 AMPS L3 3.9063exp-3 0.015625 0.03125 0.0625 0.125
40025 kW 0.004 0.016 0.032 0.064 0.128
40026 kW 0.004 0.016 0.032 0.064 0.128
40027 kW 0.004 0.016 0.032 0.064 0.128
Per the Veris implementation, to obtain true engineering units, the values returned from
the registers in the ViewPoint Register Descriptions Table must be multiplied by the
scaling values listed in Table 23: Veris Multipliers for Integer Registers 40001-40027 .
