Siemens POLYMOBIL Plus Service Manual

POLYMOBIL Plus SPR8-125.061.02 Page 4 of 4 Siemens AG
Rev. 01 01.00 TD SD 24 Medical Engineering
1 - 4 Prerequisites
• Connect the POLYMOBIL Plus only to a line voltage supply (line voltage receptacle) that
complies with the requirements of VDE 0107, or corresponds to the local national
regulations.
• Disconnect the POLYMOBIL Plus at the line voltage OFF switch on the operating
console and disconnect the line voltage plug prior to any service work.
• Remove or insert boards with the generator switched OFF only; observe
ESD guidelines when handling boards.
Replacing damaged or missing screws 1
• Damaged or missing screws may only be replaced by steel screws as specified in the
installation drawings conforming to DIN267 and must have the specified tensile strength.
Cleaning 1
• The unit must always be switched off or disconnected before cleaning.
• Use only water to clean the unit or a lukewarm, dilute solution consisting of water and a
household cleaning agent.
• Do not use abrasive cleaning agents or organic solvents such as benzine, alcohol or spot
remover. Do not spray with water.
• For additional information, refer to the Operating Instructions "Cleaning/Disinfection".
All Allen screws must have a tensile strength rating of 8.8.
CAUTION

Siemens POLYMOBIL Plus Specifications

General

Type	Mobile X-ray System
X-ray Tube Focal Spot	0.6 / 1.2 mm
kV Range	40 - 125 kV
mAs Range	320 mAs
Display	High-resolution Touchscreen
Image Receptor Compatibility	CR cassettes
