Siemens POLYMOBIL Plus - Checking the Assemblies; Preparation for Assembly Checks

2 - 1
Siemens AG SPR8-125.061.02 Page 1 of 8 POLYMOBIL Plus
Medical Engineering Rev. 01 01.00 TD SD 24
Checking the assemblies 2
Preparation 2
When working on the open system, there is the danger of
Electric shock
!
• The capacitor bank can still be charged.
Do not attempt to work on the system while this condition exists.
• For details see chapter "Prerequisites".
Fig. 1
V
C
C
+
-
R
5
C
1
R
3
R
4
WARNING
