5 / 94
Siemens RDF301, RDF301.50..., RDF600KN, RDF600KN/S Basic Documentation CE1P3171en
Building Technologies 2017-12-07
1.2 New functions
Availability of new functions depends on the software version used; see table
below.
RDF301 /
RDF301.50 /
RDF301.50H
RDF600KN
RDF600KN/S
Firmware updates SW = V4.1 SW < V1.8 SW = V1.8 SW >= V2.0
SW >= V1.0
Hotel presence
Standard presence mode
External sensor error
message Er3
Window contact
Operating mode switchover
contact
Fan stage in dead zone
(Comfort)
Fan start delay
Room temperature: S-Mode
object Economy heating
setpoint
Room temperature: S-Mode
object Economy cooling
setpoint
1.3 Reference documents
Subject Ref Doc No. Description
Semi-flush mount room
thermostats with KNX
communications,
RDF301, RDF301.50,
RDF600KN, RDF600KN/S
[1] CE1N3171 Data Sheet
[2] CE1B3171 Operating Instructions
[3]
[3a]
CE1M3171
CE1M3076.3
Mounting Instructions RDF301...
Mounting Instructions RDF600KN…
KNX Manual [4] Handbook for Home and Building Control – Basic Principles
(http://www.knx.org/knx-en/training/books-documentation/knx-association-
books/index.php)
Synco and KNX (see
)
[5] CE1N3127 KNX bus, Data Sheet
[6] CE1P3127 Communication via the KNX bus for Synco 700, 900 and
RXB/RXL, Basic Documentation
[7]
in HIT
Planning and commissioning protocol,
communication Synco 700
[8] CE1N3121 RMB795 central control unit, Data Sheet
[9] CE1Y3110 KNX S-Mode data points
[10] -- Product data for ETS
[11] CE1J3110 ETS product data compatibility list
[12] 0-92168en Synco Application Manual
Desigo
engineering documents
[13] CM1Y9775 Desigo RXB integration – S-Mode
[14] CM1Y9776 Desigo RXB / RXL integration – Individual Addressing
[15] CM1Y9777 Third-party integration
[16] CM1Y9778 Synco integration
[17] CM1Y9779 Working with ETS
Apogee [18] 565-132 Installation Instructions: KNX driver for PXC Modular
