6-26
System Manual
C79000-G8576-C199-06
You wish to reference modules at Slots 11, 59, 75 and 99 in the
S5-135U/155U PLC via the COR 923C, from base address 10.
Setting the base address:
Switch
Setting
Meaning
off on
Base address:
S2.1 x –
S2.2 x Significance 16
S2.3 x Significance 8 8
S2.4 x Significance 4
S2.5 x Significance 2 +2
S2.6 x Significance 1
= 10
Activating the required slots for the S5-135U/155U PLC:
Switch
Setting
Meaning Slot No. in the
S5-135U/155U
Operable Slots End
Address
off on
S3.1 x Base address + 0 11 11 10
S3.2 x Base address + 1 27
S3.3 x Base address + 2 43
S3.4 x Base address + 3 59 59 13
S3.5 x Base address + 4 75 75 14
S3.6 x Base address + 5 83
S3.7 x Base address + 6 91
S3.8 x Base address + 7 99 99 17
Example of
Address Activation
Multiprocessor Operation/Coordinators
