18HEMO Pod
Figure B-21HEMO Pod Connectors (Refer to Table B-18.)
Figure B-22Press Adapter Input (Refer to Table B-19.)
Table B-18 HEMO Pod Connector Signals
Pin No. PRESSURE FRONT END
INTERFACE
Temp A C.O./Temp B IBP SC 7000 / 9000XL
1 +SIG (P1) TEMP 1 TEMP 2 CNTRLH
2GND GND
3 GND GND GND CNTRLL
4 +EXCIT (P1) GND .7R37 DATH
5 +EXCIT (P2) GND TBLD VDCRTN
6 GND GND TINJ VDC
7 GND GND GND DATL
8+SIG (P2)
9-SIG (P1)
10 GND
11 -EXCIT (P1)
12 GND
13 -EXCIT (P2)
14 GND
15 -SIG (P2)
Table B-19 PRESS Input Connector
Pin No. A, B, C, D Pin No. A, B, C, D
1 +EXCIT 6 +SIGNAL
27
3-EXCIT 8 GND
4 Cable In 9
5 -SIGNAL 0
Temp A C.O./Temp B
IBP SC 7000
/ 9000XL
Pressure Front End Interface Connector
1
7
3
9
0
84
2
6
5
