SC 7000 and SC 9000XL Patient Monitors Service Manual
ASK-T898-03-7600 Siemens Medical Systems, EM-PCS Danvers 3
7k9kXLSM.c1.CD_ROM.fm/04-99/kaupp
NOT A CONTROLLED DOCUMENT
4 Related
Documentation
• User Guide for the installed software version
• Hardware and Software Installation instructions
• Service Setup Instructions
5 Cleaning
Contact with chlorine bleach, Cidex, or body fluids does not damage or
cause discoloration of any component case of an SC 7000 or SC 9000XL
installation. Clean Base Unit, pods, cartridges, and cables using a 95%
solution of isopropyl alcohol. If contaminants enter the chimney (slot in
middle of unit), flush chimney with one cup of water not under pressure.
Note: Bac solution mars the finish of the monitor case.
6 Technical Data
A complete set of technical data is given in the Operating Instructions (User
Guide) for the installed software version.
7 Brief Operating
Instructions
This section provides a brief overview of SC 7000 and SC 9000XL monitor
controls to assist technical personnel in servicing and testing procedures. For
detailed operating instructions and additional information, consult the monitor’s
User Guide and supplements for the installed software version.
7.1 SC 7000 and SC
9000XL Monitor
Controls
Control of all SC 7000 and SC 9000XL functions is via fixed keys that have
tactile feedback, and a rotary knob for selecting from on-screen menus.
Turning the rotary knob locates different menu items, and pressing the knob
in selects the item. Depending on the item selected, pressing the knob in may
either bring up another menu or initiate an action. “Ghosted” items cannot be
selected.
The Remote Keypad has an identical set of keys and a display knob, that
mimic the action of those on the SC 7000 or SC 9000XL Base Unit. Except
for the ON/OFF key, the monitors can be operated from either the base unit
or the Remote Keypad.
8 Peripheral Device
Controls
Individual cartridges, pods, and peripheral devices (such as the recorder)
also have fixed keys that control specific aspects of their operation. Refer
to the monitor’s User Guide for specific key functions.
9 Passwords
SC 7000 and SC 9000XL systems have two kinds of basic password
protection -- clinical password, and service password. Clinical and service
passwords are entered via selections on a keypad that appears whenever
a password-protected function is selected. To enter a password, turn the
rotary knob to highlight a number and then press in on the knob to enter the
number. When all numbers of the password have been entered, turn the
knob to highlight “Accept,” and press in on the knob.
9.1 Clinical Password
The clinical password is available to authorized supervisory personnel at
the clinical site as well as to service personnel.
9.2 Service Password
The service password is available to only authorized service personnel.
10Menus
10.1Main Menu
The Main Menu uses a three column layout for menu navigation: Level 1 =
main selection list, Level 2 = workspace A, and Level 3 = workspace B.
Selecting any function category on Level 1 of the Main Menu brings up a
list of selectable related functions and menus in Level 2. Selecting a
function in Level 2 produces a similar result in Level 3.
Press MENU fixed-key to display
MAIN
screen with overlay of Main Menu.
