Service Manual SC 7000 and SC 9000XL Patient Monitors
6 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.c1.CD_ROM.fm/04-99/kaupp
11) Enter Service password, 4712, and select Accept.
12) Select More → “Copy Setups to Card.”
13) Select “Copy All.”
14) Wait for message “Memory Card Tansfer Complete.” Then press Main
Screen key and remove Data Card from monitor.
15) Insert card into monitor connected to next CPS to be identically
configured.
16) Press Menu key, and select Monitor Setup → Biomed → Service
17) Enter Service password, 4712, and select Accept.
18) Select More → “Copy Setups to Monitor.”
Note: In actuality, this copies the setups to the CPS or IDS, which in
turn reconfigures the setup of the monitor when “Restore Setups”
function is invoked.
19) Select “Replace All.”
20) Wait for message “Memory Card Tansfer Complete.” Then press Main
Screen key and remove Data Card from monitor.
21) Press Menu key, and select Save/Restore → Restore Setup.
22) Select “Default” → “Patient and Monitor Settings.”
23) Repeat steps 15 through 22 until all CPSs/IDSs to be identically
configured have been set up.
10.5Diagnostic Log Upload
Procedure
The monitor is constantly checking its performance during monitoring. If
errors occur, they are logged in the unit and stored in non-volatile memory.
The logs are useful in diagnosing problems remotely at the factory. The
following procedure can upload the diagnostic logs from approximately 10
to 16 monitors to a Data Card, depending on the size of the individual logs.
Assure that Write/Protect switch on Data Card is set to Write position.
1) With
MAIN
screen displayed on monitor, insert and firmly seat Data
Card into memory slot.
2) Press Menu key, and select Monitor Setup → Biomed → Logs
3) Select “Copy All Logs.”
4) Remove Data Card from monitor, and repeat steps 1, 2 and 3 for next
monitor from which logs are to be uploaded.
5) After all required diagnostic logs have been uploaded to the Data Card,
send the Card (in its preaddressed return case when possible) to:
Siemens Medical Systems, Inc.
EM-PCS
16 Electronics Avenue
Danvers, MA 01923 U.S.A.
Att: SC 7000 / SC 9000XL Project Manager
Note: The battery in the Data Card must be recharged for a period of
12 hours approximately every six months. Any SC 7000 or SC
9000XL Monitor powered by a CPS, IDS, or PSL can be used to
recharge the Data Card. Insert the card into the Monitor, and allow it
to remain in the monitor for 12 hours.
