SC 7000 and SC 9000XL Patient Monitors Service Manual
ASK-T898-03-7600 Siemens Medical Systems, EM-PCS Danvers 35
7k9kXLTM.c2.CD_ROM.fm/04-99/kaupp
NOT A CONTROLLED DOCUMENT
The power supply uses a soft switching (quasi-resonant) square wave
forward converter topology operating at 500 Khz. No power factor
correction is provided.
Fuses (not user accessible) have the following approvals; UL recognized,
Semko approved, CB certified, BSI approved.
15I
NFINITY
Docking
Station (IDS)
An I
NFINITY
Docking Station (IDS) is active device that combines the
functions of a passive docking station with the networking and interface
functions of an I
NFINITY
Network CPS. With its separate power supply, it
replaces the Basic CPS and Docking Station combination. As a docking
station, it serves as a secure mount for Patient Monitors in Pick-and-Go
operations. When equipped with a MIB Option, it provides the functionality
of a Device CPS in combination with a Breakout Box.
The I
NFINITY
Docking Station Power Supply operates from 100-120Vac or 200-
240Vac (auto-ranging) @ 50/60Hz, to supply 12VDC @ 10.8A to an Infinity
Docking Station, for powering Patient Monitors mounted on the docking
station. The Power Supply can also power an SC 7000, SC 9000XL. SC
9000, or SC6000 series monitor directly as a replacement for the AC Power
Adapter (PSL) in standalone installations.
