2.3 Modules, PODs, and
Peripherals
The following modules, PODs, and peripherals have no field-replaceable
parts or subassemblies.
• MultiMed and MultiMed 12 Pods, tcpO
2
/CO
2
Pod, NeoMed Pod
•etCO
2
Module
• CPS/IDS (except for dc power cable in IDS-PS, and MIB Options in
IDS, which are field-replaceable)
• Hemo4 Pod / Hemo2 Pod, HemoMed Pod
• Remote Display
• PCMCIA Card
3 Safety Precautions
Remove all power sources, attached modules and cables, before
attempting to replace any items or open the monitor case.
&DXWLRQ
Open monitor only in a static-protected environment. Observe
standard precautions for protecting the equipment from static
electricity.
4 Replaceable Parts
and Subassemblies
That DO NOT
Require Opening the
Monitor
The following components and subassemblies can be replaced without
opening the monitor.
• rotary knob
• front bezel language and monitor model labels
• foot pads
• external battery (optional)
• external battery compartment door and battery ejector spring
• main battery
• power cable and speaker subassembly
• NP filters
• NP pump subassembly
• monitor handle
• rear housing side panels
4.1 Replacing Rotary
Knob
The rotary knob (
0
in Figure 3-10 on page 51) is press fitted onto the metal
shaft of the optical encoder subassembly. It must be removed very carefully
if it is to be reinstalled.
To remove the knob, grip it
very
firmly with vise-grips or a similar tool, and
pull it straight out and off of the metal shaft. Avoid turning the knob.
Note: Placing a piece of cloth around the knob should prevent
scratching by the vise-grips, and allow the knob to be reused.
To install or reinstall a knob, align and firmly press knob onto shaft.
4.2 Replacing Front Bezel
Labels
The Language Label kit ships with a set of language labels and SC 7000
and SC 9000XL model labels (see
in Figure 3-10 on page 51). A
SIEMENS metal logo label ships with the bezel (see
in Figure 3-10).
