SC 7000 and SC 9000XL Patient Monitors Service Manual
ASK-T898-03-7600 Siemens Medical Systems, EM-PCS Danvers 69
7k9kXLSM.c4.CD_ROM.fm/04-99/kaupp
NOT A CONTROLLED DOCUMENT
12.1.2 Channel A 3) With
MAIN
screen displayed, connect BP output from simulator to first
input, channel A, on HEMO POD adapter.
4) Set IBP simulator for a static pressure = 0 mmHg.
Note: “Zero Required” message, appears on display.
Monitor Zero Function 5) Press Zero All key on HemoMed Pod.
Note: All four pressures are zeroed simultaneously in the monitor,
even if only channels A and B are to be used in the HemoMed Pod.
6) Verify that a “Zero Accepted” message that changes to “Static
Pressure” appear in the message field.
7) Select a pulsatile pressure on patient simulator.
8) Assure that Cal Factor and Manometer Cal are set to 100.
9) Verify that pressure reading on monitor agrees with values generated
by pressure signal from simulator.
If verifying only SC 7000, omit remaining steps in this section and go to
section 12.2. If also verifying HEMO POD, go on to step 10.
12.1.3 Channel B 10) Unplug BP adapter cable from channel A on HEMO POD and plug it
into channel B.
11) Verify that pressure reading on monitor agrees with values generated
by pressure signal from simulator.
12) Do either step a or step b as appropriate.
a If HemoMed Pod has four channels, unplug the BP adapter cable
from channel B and plug it into channel C. then go on to step 13.
b If HemoMed Pod has only two channels, bypass remaining steps
of this section and go to section 12.2.
12.1.4 Channel C 13) Unplug BP adapter cable from channel B on HemoMed Pod and plug it
into channel C.
14) Verify that pressure reading on monitor agrees with values generated
by pressure signal from simulator.
12.1.5 Channel D 15) Unplug BP adapter cable from channel C on HemoMed Pod and plug
it into channel D.
16) Verify that pressure reading on monitor agrees with values generated
by pressure signal from simulator.
17) Unplug simulator input adapter cable from HemoMed Pod, and go on
to section 12.2.
12.2 Cardiac Output
Function
1) Plug C.O. output from simulator into C.O. test adapter cable, and plug
adapter cable into C.O input on HemoMed Pod.
2) When READY appears in CO parameter field verify that blood
temperature indication is 37±0.15°C.
3) Press C.O. START key on simulator, and verify an Injectate
Temperature indication of 1±0.2°C.
13HEMO POD2/4
Refer to Figure 4-3 on page 70 for test setup.
13.1 IBP Function
IBP parameter boxes for up to two pressures for HEMO 2 POD or up to four
pressures for HEMO 4 POD display automatically when IBP signal from
POD is plugged into monitor, when Display Mode is set to automatic.
