Siemens SCALANCE X-300

Technical specifications
8.4 Technical specifications for X-300EEC
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
167
Number of frames
at 100 Mbps at 1000 Mbps
At a frame length of (in bytes):
45290 452899 256
23496 234962 512
11973 119732 1024
9615 96154 1280
8127 81274 1518
Note
The following applies to IE Switches X-300:
The number of IE Switches X-300 connected in a line influences the frame propagation time.
When a frame passes through an IE Switch X-300, it is delayed by the Store&Forward
function of the IE Switch X-300
 with a 64 byte frame length by approx. 10 microseconds (at 100 Mbps)
 with a 1500 byte frame length by approx. 130 microseconds (at 100 Mbps)
This means that the more IE Switch X-300 devices the frame passes through, the longer the
frame delay.
8.4 Technical specifications for X-300EEC
8.4.1 X-300EEC construction, installation and environment
Table 8- 50 Construction of the X-300EEC
Device:
SCALANCE
Dimensions (W x H x D)
[mm]
Weight [g] IP degree of protection
X-300EEC
 216 x 140 x 99
(without bracket)
 216 x 203 x 99 (with
bracket)
 1 800 (1 power supply unit 24 V DC)
 2 030 (2 power supply units 24 V DC)
 1 850 (1 power supply unit 100...240V AC / DC 60...250
V)
 2 120 (2 power supply units 100...240V AC / DC 60...250
V)
IP30 with connectors
inserted
(all variants)
