Approvals, certificates, standards
9.6 Product group X-300M PoE
SCALANCE X-300
234 Operating Instructions, 10/2010, A5E01113043-10
Table 9- 8 Overview of the approvals of the SCALANCE X-308-2M PoE - part 2
C-TICK CE ATEX95 Zone 2
1)
AS/NZS 2064 (Class A) EN 61000-6-4 Class A,
EN 61000-6-2
EN 60079-15:2005
EN 60079-0:2006
II 3 G Ex nA II T4
KEMA nn ATEX nnnnX
● ● ●
1
For temperature information "T.." or the maximum ambient temperature "Ta:..", 60° C applies.
Note
Shipbuilding approval
You will find shipbuilding approvals on the Internet on the pages of Siemens Industry
Automation Customer Support under the following entry ID:
"Entry list" tab > entry type "Certificates"
9.6.4 X-300M PoE mechanical stability in operation
The switch meets the following requirements for mechanical stability:
IEC 60068-2-6 (vibration)
● Securing on a DIN rail
5 – 9 Hz: 3.5 mm
9 – 150 Hz: 1 g
1 octave/min, 20 sweeps
IEC 60068-2-27 (shock)
● Securing on a DIN rail
15 g, 11 ms duration, 6 shocks per axis
