Siemens SCALANCE X-300

Technical specifications
8.5 XR-300M EEC technical specifications
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
173
Table 8- 68 Full wire speed switching
Number of frames
at 100 Mbps at 1000 Mbps
at a frame length of [bytes]
148 810 1 488 095 64
84 459 844 595 128
45 290 452 899 256
23 496 234 962 512
11 973 119 732 1 024
9 615 96 154 1 280
8 127 81 274 1 518
Note
The following applies to IE Switches X-300:
The number of IE Switches X-300 connected in a line influences the frame propagation time.
When a frame passes through the switch, this is delayed by the Store&Forward function of
the IE Switch X-300 by the following values:
 64 bytes frame length: Delay of approx. 10 microseconds (at 100 Mbps)
 1 500 bytes frame length: Delay of approx. 130 microseconds (at 100 Mbps)
The more IE Switches X-300 a frame runs through, the higher the frame delay.
8.5 XR-300M EEC technical specifications
8.5.1 XR-300M EEC construction, installation and environment
Note
With modular devices (M), take the values of media modules and transceivers into account
Table 8- 69 Construction
Device:
SCALANCE
Power supply Dimensions W x H x D (mm) Weight (in kg) IP degree of
protection
1 x 24 V DC 483 x 44 x 305
1 height unit (1HU)
6.5 IP20
2 x 24 V DC 483 x 44 x 305
1 height unit (1HU)
6.8 IP20
1 x 100 to 240 V AC 483 x 44 x 305
1 height unit (1HU)
6.6 IP20
XR324-4M EEC
2 x 100 to 240 V AC 483 x 44 x 305
1 height unit (1HU)
7.0 IP20
