Siemens SCALANCE X-300

Technical specifications
8.1 X-300 technical specifications
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
147
8.1.2 X-300 connectors and electrical data
Connectors and electrical data
Table 8- 4 Connectors
Connection of end devices or network components: Plug-in terminal block
Connector for:
Device:
SCALANCE
over twisted pair over FO cable Power supply Signaling contact
X304-2FE 4 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps
(half / full duplex)
2 x SC duplex socket (MM)
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin 1 x 2-pin
X306-1LD FE 6 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps
(half / full duplex)
1 x SC duplex socket (SM)
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin 1 x 2-pin
X307-3 7 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps (half
/ full duplex)
3 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseSX)
1 x 4-pin 1 x 2-pin
X307-3LD 7 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps (half
/ full duplex)
3 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
1 x 4-pin 1 x 2-pin
X308-2 7 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps (half
/ full duplex)
1 x RJ-45 socket with MDI-X
pinning 10/100/1000 Mbps
(half/ full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseSX)
1 x 4-pin 1 x 2-pin
X308-2LD 7 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps (half
/ full duplex)
1 x RJ-45 jacks with MDI-X
assignment 10/100/1000 Mbps
(half / full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
1 x 4-pin 1 x 2-pin
X308-2LH 7 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps (half
/ full duplex)
1 x RJ-45 socket with MDI-X
pinning 10/100/1000 Mbps
(half/ full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
1 x 4-pin 1 x 2-pin
X308-2LH+ 7 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps (half
/ full duplex)
1 x RJ-45 jacks with MDI-X
assignment 10/100/1000 Mbps
(half / full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
1 x 4-pin 1 x 2-pin
X310 7 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps (half
/ full duplex)
3 x RJ-45 jacks with MDI-X
assignment 10/100/1000 Mbps
(half / full duplex)
- 1 x 4-pin 1 x 2-pin
X310FE 10 x RJ-45 jacks with MDI-X
assignment 10/100 Mbps (half
/ full duplex)
- 1 x 4-pin 1 x 2-pin
