Description of the device
4.2 Product groups
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
71
4.2.8 MM900 media modules
Possible attachments
The MM992-2CUC media module has the following:
● 2 x 10/100/1000 Mbps, RJ-45 ports electrical with securing collar
Figure 4-25 MM992-2CUC [9922GA]
[Device labeling in square brackets]
Possible attachments
The MM992-2CU media module has the following:
● 2 x 10/100/1000 Mbps, RJ-45 port electrical without securing collar
Figure 4-26 MM992-2CU [9922SA]
[Device labeling in square brackets]
Note
Only the media module MM992-2SFP may be fitted with approved SFP transceivers. The
SFP media module can be fitted with up to two SFPs.
