Description of the device
4.5 Components of the product
SCALANCE X-300
Operating Instructions, 10/2010, A5E01113043-10
93
4.5.5 Components of the XR-300M EEC product
Note
Notes on the devices
When shipped, all devices have a C-PLUG exchangeable medium.
When shipped, the slots for the media modules have a dummy cover fitted.
Labels to identify the installed MM900 media modules are supplied with the modular
devices (M).
The consignment of a SCALANCE XR-300M EEC consist of the device itself and the
following parts:
● 2 mounting brackets and 8 screws (M3x5 recessed head, drive: Torx) for 19" rack
mounting
● Connecting cable for the diagnostics port
● Operating Instructions (compact) SCALANCE XR-300 M EEC.
● Product CD with documentation and software
● With devices with power supply 100 to 240 V AC / 60 to 250 V DC:
– A 3-pin terminal block (or two terminal blocks for redundant power supply) for the
signaling contacts.
– A 3-pin terminal block (or two terminal blocks for redundant power supply) for the
power supply.
● With devices with 24 to 48 V DC power supply:
– A 2-pin terminal block (or two terminal blocks for redundant power supply) for the
signaling contacts.
– A 4-pin terminal block (or two terminal blocks for redundant power supply) for the
power supply.
4.5.6 Components of the X308-2M PoE product
Interfaces
Type RJ-45 port electrical
10/100/1000 Mbps
Module slots
X308-2M PoE 4 2
Components of the product
The following parts ship with a SCALANCE X-300M PoE:
● Device with C-PLUG exchangeable medium
● 4-pin terminal block for the power supply
