4.5 Components of the product
SCALANCE X-300
90 Operating Instructions, 10/2010, A5E01113043-10
4.5.1 Components of the product
The following components are supplied with a SCALANCE X-300:
● Device with C-PLUG exchangeable medium.
● A four-pin terminal block for the 24 VDC power supply.
● A two-pin terminal block for the signaling contact.
● Operating Instructions (compact)
● Product CD with documentation and software.
4.5.2 X-300M components of the product
Note
When shipped, all devices have a C-PLUG exchangeable medium.
Note
When shipped, the slots for the media modules have a dummy cover fitted.
Note
Labels to identify the installed MM900 media modules are supplied with the modular devices
(M).
Table 4- 1 Overview of the components shipped with the X-300M product group
Plug-in terminal block
Device:
SCALANCE
Variant
(signaling
contact)
2-pin
(24V)
4-pin
Device BAK Product CD
X308-2M (-) ● ● ● ● ●
4.5.3 Components of the XR-300M product
Note
When shipped, the slots for the media modules have dummy covers fitted.
