Graphics
11.5 XR-300M EEC dimension drawings
SCALANCE X-300
264 Operating Instructions, 10/2010, A5E01113043-10
Mounting support for 19" rack mounting of the X-300EEC switch
Figure 11-19 Rack mounting of two X-300EECs fastened together (view from below)
Table 11- 1 Legend for rack mounting of two X-300EECs fastened together
No. Number needed Name
1 2 Plate for side
2 12 Spring washer SN60727-4-NrSt
3 12 Hexagonal nut ISO 4032-M4-8
4 1 Mid part of mounting support
