Siemens SICLOCK TC 400

15-111© Siemens AG 2007 All Rights Reserved
SICLOCK
®
TC 400
Circuit Diagrams 15
15.1 Terminal assignment
Figure 15-1 Terminal assignment of the SICLOCK TC 400
OUTPUT 1 GND
OUTPUT 1
OUTPUT 2
OUTPUT 2 GND
OUTPUT 3A
OUTPUT 3B
RADIO CLOCK GND
RADIO CLOCK 1A
RADIO CLOCK 1B
RADIO CLOCK 2A
RADIO CLOCK 2B
COMMON
ALARM OUT
WARNING OUT
12
13
14
5
6
A
B
RS422
2
1
24 V / 20 mA
3
4
TTY (active)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
8
9
48 V
7
passive
Radio Clock 1
8
9
48 V
7
active
Radio Clock 1
passive
Radio Clock 2
10
11
48 V
10
11
48 V
active
Radio Clock 2
X2
