6-36
© Siemens AG 2007 All Rights Reserved
SICLOCK
®
TC 400
Functional check
The receive signal of the radio clocks is displayed on the front panel with the
"RADIO CLOCK 1" and "RADIO CLOCK 2" LEDs.
The status of the radio clock is displayed in the /Inputs/Input 1/Status (0.20.02)
(or
/Inputs/Input 2/Status (0.21.02)
) parameter.
Possible states:
GPS (SICLOCK GPS1000 and SICLOCK GPSDEC)
GPS (faulty)
The signal reception is temporarily faulty.
DCF77 (SICLOCK DCFRS and SICLOCK GPSDEC)
DCF77 (faulty)
The signal reception is temporarily faulty.
Serial
Meinberg
Receiving Meinberg format
NMEA
Receiving NMEA format
Telegram (faulty)
Fault detected in telegram or telegram failure
No signal
The connection of individual sources to the external synchronization is described
in the following.
