Configuration Tool
7-46
© Siemens AG 2007 All Rights Reserved
SICLOCK
®
TC 400
Requirements
PC
Screen resolution of at least 1280x1024 pixels
Java Runtime, at least V1.4.0 or higher
Web browser, e.g. Microsoft Internet Explorer
Connection via one of the four Ethernet ports of the device
SICLOCK TC 400
Assignment of an IP address on the device
A valid IP address must be assigned for the Ethernet port of the device that is
to be used for the configuration.
Default addresses as delivered each with subnet mask 255.255.255.0:
Port 1: 192.168.1.10
Port 2: 192.168.2.20
Port 3: 192.168.3.30
Port 4: 192.168.4.40
PC must be in the same subnet.
Parameters, entries and lists
A parameter is considered as a group of associated values. Each value is desig-
nated as an entry of its parameter.
Parameters of the same kind can form a list. Such lists are displayed as [ ].
Parameters are identified by their unique parameter number. The parameter
number is always in three parts, e.g. 0.05.12.
Notice
Entries can be edited individually, but not read or written individually. The param-
eter is always read or written with all its entries. If a list is being considered, the
entire list is read or written.
