Parameter tree Tree display of the parameters
The parameters are divided between the individual menus and submenus in
the tree.
Online mode:
In online mode, you can open a context menu by right-clicking the parame-
ter/entry. The following functions are available:
• Read parameter individually
• Write parameter individually
• Reset parameter to factory setting
See Reading parameters / writing parameters / resetting parameters to
factory settings (Section 7.3.4).
Symbols:
• Write protection – the parameter cannot be edited
The current authorization level does not permit write access to this parame-
ter.
• Unrestricted access
The current authorization level permits reading, editing and writing of the
parameter
• Unrestricted access without upload – critical operating parameter
The current authorization level permits reading, editing and writing of the
parameter
To protect such parameters in the device, the parameter must be explicitly
selected and written individually.
See Reading parameters / writing parameters / resetting parameters
to factory settings (Section 7.3.4)
• Display parameters
Display parameters can only be read and are typically actual values.
To refresh the actual value display, activate the automatic update .
• Entry – this is a parameter entry
Parameter table Tabular display of the parameters
You can edit the parameter values in this view, see Editing parameters
(Section 7.3.3).
Online mode:
In online mode, you can open a context menu by right-clicking the parame-
ter/entry. The following functions are available:
• Read parameter individually
• Write parameter individually
• Reset parameter to factory setting
See Reading parameters / writing parameters / resetting parameters to
factory settings (Section 7.3.4).
Table 7-3 Operator options and displays in the Parameters tab
Field/Button Meaning/Instruction
