Technical Specifications
B-9
DP/PA Link and Y Link Bus Couplings
A5E00193841-011
B.1.4 Transportation and storage conditions
Transport and storage of modules
The described components exceed the requirements of IEC 61131, Part 2, as
regards transportation and storage requirements. The following values apply to
modules that are transported or stored in the original packaging.
Table B-4 Transportation and storage conditions
Type of condition
Permissible range
Free fall (in transport packaging) v 0.3 m
Temperature From –40 C to + 70 C
Air pressure From 1080 to 660 hPa (corresponds to a
height of –1000 to 3500 m)
Relative air humidity From 10 to 95 %, without condensation
Sinusoidal vibrations in accordance with
IEC 60068-2-6
5 - 9 Hz: 3.5 mm
9 - 150 Hz: 9.8 m/s
2
Shock in accordance with IEC 60068-2-29 250 m/s
2
, 6 ms, 1000 shocks
B.1.5 Mechanical and climatic ambient conditions for operation
Operating conditions
The described components are designed for use in a fixed, sheltered location. The
operating conditions exceed the requirements of IEC 61131 Part 2.
The described components meet the operating conditions of Class 3C3 in
accordance with DIN EN 60721 Part 2.
