DP Slaves Connectable to a Y Link
C-3
DP/PA Link and Y Link Bus Couplings
A5E00193841-011
Table C-3 CPUs that can be used as I slaves with various I/O ranges
Slave name
Path
1)
Device master
file
Input bytes Output
bytes
Number of
slaves
2)
S7-300 CPU 315-2DP
(...-2AF01-... or
...-2AF02-...)
SPS\SIMATIC Siem802f.gs* Max. 122 Max. 122 1
3)
S7-300 CPU 315-2DP
(...-2AF03-... )
SPS\SIMATIC Sie3802f.gs* Max. 244 Max. 244 1
3)
S7-300 CPU 316-2DP SPS\SIMATIC Siem806f.gs* Max. 244 Max. 244 1
3)
S7-300 CPU 318-2DP SPS\SIMATIC Siem807f.gs* Max. 244 Max. 244 1
3)
S7-400 CPU 412-1 SPS\SIMATIC Siem80c5.gs* Max. 244 Max. 244 1
3)
S7-400 CPU 412-2 SPS\SIMATIC Siem80c6.gs* Max. 244 Max. 244 1
3)
S7-400 CPU 414-2 SPS\SIMATIC Siem80c7.gs* Max. 244 Max. 244 1
3)
S7-400 CPU 414-3 SPS\SIMATIC Siem80c8.gs* Max. 244 Max. 244 1
3)
S7-400 CPU 416-2 SPS\SIMATIC Siem80ca.gs* Max. 244 Max. 244 1
3)
S7-400 CPU 416-3 SPS\SIMATIC Siem80cb.gs* Max. 244 Max. 244 1
3)
S7-400 CPU 417-4 SPS\SIMATIC Siem80cc.gs* Max. 244 Max. 244 1
3)
1)
In the hardware catalog based on “PROFIBUS-DP\Additional FIELD DEVICES”
2)
Number of slaves of the same kind that exhaust the capacity of the I/O quantity structure of the Y link
3)
Applies when the maximum number of slaves is installed
