Order Numbers and Accessories
D-2
DP/PA Link and Y Link Bus Couplings
A5E00193841-011
D.2 Accessories for PROFIBUS-DP
Table D-3 Order numbers for PROFIBUS-DP accessories
Accessories
Order number
PROFIBUS-DP bus connector (up to
12 MBaud)
Without programming port
6ES7 972-0BA12-0XA0
With programming port
6ES7 972-0BB12-0XA0
PROFIBUS-DP FastConnect bus connector
Without programming port
6ES7 972-0BA50-0XA0
With programming port
6ES7 972-0BB50-0XA0
PROFIBUS-DP bus cable
Normal (flexible)
6XV1 830-0AH10
Drum cable (strong)
6XV1 830-3BH10
PROFIBUS-DP terminator 6ES7 972-0DA00-0XA0
D.3 PROFIBUS-PA accessories
Table D-4 Order numbers for PROFIBUS-PA accessories
Accessories
Order number
PROFIBUS-PA bus cable (cable type A) 6XV1 830-5AH10
Configuration using the SpliTConnect connection system
Create the configuration using the SpliTConnect connection system. Using the
SpliTConnect connection system, it is possible to install PROFIBUS-PA segments
easily in accordance with IEC 61784-1:2002 Ed1 CP 3/2 with field device
connecting points in both intrinsically safe and non-intrinsically safe areas. The
SpliTConnect system consists of the following components:
Accessories Description Order number
SpliTConnect tap T-connector for PA field
device
6GK1 905-0AA00
SpliTConnect M12 outlet Connector for M12
connection
6GK1 905-0AB00
SpliTConnect coupler Connection element
between the taps
6GK1 905-0AC00
