C-1
DP/PA Link and Y Link Bus Couplings
A5E00193841-011
DP Slaves Connectable to a Y Link
Using STEP 7 of version V5.2 or higher, many DP slaves can be directly
configured in the underlying DP master system of a Y link.
Table C-1 Examples of directly configurable DP slaves
Group (path
1)
) Configurable slaves MLFB
Preconfigured stations PC station as a DP slave –
S7-300 CP 342-5 DP All
DP/AS-i DP/AS-i Link 6ES7 156-0AA00-0XA0
DP/AS-i DP/AS-i lLink 20 6GK1415-2AA00
ENCODER SIMODRIVE Sensor 6FX2001-5xPxx
ET 200B Most components with the exception
of S7 slaves ET 200B-4AI,
ET 200B-4/8AI and ET 200B-4AO
Not
6ES7 134-0HF01-0XB0,
6ES7 134-0KH01-0XB0,
6ES7 135-0HF01-0XB0
ET 200L Most components with the exception
of the extendable module L-SC-...
ET 200S Most components with the exception
of the IM 151 / CPU
Not
6ES7 151-7AA00-0AB0
Function modules IM 178-4 6ES7 178-4BH00-0AE0
IPC Direct control key module
NC IM 319N (slave) 6FC5012-0CA02-0AA0
Control unit SIPART DR**
Switchgear Interface module DP/RS 485 3RK1000-0JC80-0BA1
SIMOCODE-DP
SIMADYN SIMADYN D SS52 6DD1688-0AE2
1)
In hardware catalog based on “PROFIBUS-DP”
Nearly all of the components in the following groups are directly configurable:
ET 200C,
ET 200U, IDENT, SIMATIC, SIMODRIVE, SIMOREG, SIMOVERT and SIPOS.
DP slaves that are not allowed by STEP 7 can be configured as DPV0 standard
slaves by means of the device master file, provided that they are not subject to the
restrictions presented below.
