Technical Specifications
B-11
DP/PA Link and Y Link Bus Couplings
A5E00193841-011
Tests for mechanical ambient conditions
The following table provides information on the type and scope of the tests for
mechanical ambient conditions.
Table B-6 Test for mechanical ambient conditions
Test for ...
Test standard Comments
Vibrations Oscillations tested in
accordance with IEC
60068, Parts 2–6
(sine)
Vibration type:
frequency sweeps with a rate of change of 1
octave per minute.
10 Hz v f v 58 Hz, constant amplitude
0.075 mm
58 Hz v f v 150 Hz, constant accelaration 1 g
Vibration duration: 10 frequency sweeps per
axis in each of the 3 vertically arranged axes
Shock Shock test in
accordance with
IEC 60068 Part 2-29
Type of shock: half-sine
Strength of shock:
15 g peak value, 11 ms duration
Shock direction:
3 shocks in both + and – direction in each of the
3 vertically arranged axes
Climatic environmental conditions
The described components may be used under the following climatic ambient
conditions:
Table B-7 Climatic ambient conditions
Ambient conditions
Permissible range Comments
Temperature:
horizontal installation
vertical installation
From 0 to 60 C
From 0 to 40 C
Y coupler 6ES7 197-1LB00-0XA0
BM Y coupler bus module
6ES7 654-7HY00-0XA0
Temperature:
horizontal installation
vertical installation
From –25 to 60 C
From –25 to 40 C
IM 157 6ES7 157-0AA82-0XA0
DP/PA coupler
6ES7 157-0AC80-0XA0
DP/PA coupler Ex [i]
6ES7 157-0AD81-0XA0
BM IM/IM bus module
6ES7 195-7HD80-0XA0
BM DP/PA coupler bus module
6ES7 195-7HF80-0XA0
Relative air humidity From 10 to 95 %, Without condensation, corresponds
to a relative humidity (RH) of 2 in
accordance with IEC 61131 Part 2
