Interrupts, error messages and diagnostics and system alarms
10.1 Status and error displays
F-TM ServoDrive
90 Equipment Manual, 02/2020, A5E47579503-AA
DI LED
Table 10- 4 DI status and error display
DI LED
Meaning
Off
Input is faulty/inactive
On
Input is error-free/active
B LED
Table 10- 5 B status and error display
B LED
Meaning
On
Braking resistor/brake chopper configured as "active"
STO LED
Table 10- 6 STO status and error display
STO LED
Meaning
On
Safety sensor is connected and has not tripped
flashes (0.5 Hz)
Safety sensor has tripped (motor is disconnected from power)
IQ LED
Table 10- 7 Status and error display IQ (encoder)
IQ LED
Meaning
On
IQ speed encoder was assigned parameters/activated
Hall LED
Table 10- 8 Status and error display Hall (encoder)
Hall LED
Meaning
On
IQ speed encoder was assigned parameters/activated
