Overview
1.1 Product description
SIMATIC IPC377G
10 Operating Instructions, 07/2022, A5E51366314-AB
1.1.2 Configuration plan
Chipset
• Intel Atom® x6000E series
Processor
• Intel Atom® x6413E Processor (up to 3.0 GHz)
Main memory
Memory expansion up to 16 GB with the following memory modules:
• 4G DDR4 SDRAM
• 8G DDR4 SDRAM
• 16G DDR4 SDRAM
The max speed of memory is up to 3200 MT/s.
The processor supports IBECC (In-Band-Error-Correction-Code), and its default value in BIOS is
"Disable".
Expandability
• 2 × M.2 Key B connector
Graphics
• Intel® UHD Graphics
Power supply
• 24 V DC (19.2 to 28.8 V)
Trusted Platform
Module (TPM)
• Without TPM
• TPM 2.0
Drives and storage media
M.2 NVMe/SATA
SSD
• Without drive
• 256GB SSD
• 512GB SSD
M.2 Module
• Support 2 × M.2 Module on the motherboard
Interfaces
Ethernet
• 2 × RJ45 Ethernet 10/100/1000 Mbps
COM
• 2 × RS232/RS422/RS485
1
(switchable), D-sub connector, 9-pin
COM (optional)
• 2 × RS232 (optional), max. 115 Kbps, D-sub connector, 9-pin
USB (external)
• 4 × USB 3.1 Gen2 (up to 10 Gb/s)
USB (internal)
• 1 × USB pin header (2 USB 2.0 ports)
USB dongle
(internal)
• 1 × USB 2.0 type A connector
DisplayPort
• Connection of a digital monitor, support DisplayPort Standard Version 1.4
• 2 × DP++
2
, support resolution up to 4096 × 2160 pixels at 60 Hz
SIM card slot
(internal)
• 1 × SIM card slot
Keyboard, mouse
Connection through USB port
Audio (optional)
Connection for analog audio source and speaker
Operating systems
Operation Systems
• Without OS
• Windows 10 Enterprise 2019 LTSC (Long Term Servicing Channel) 64-bit (MUI)
3
